扭剪扳手是做什么用的

来源:http://www.xjnwz.com 日期:2019-04-12 发布人:admin

  扭剪扳手主要是初紧螺栓的,它的使用很简单,就是对准螺栓扳动电源开关就行。电动扭剪扳手主要是终紧扭剪型高强螺栓的,它的使用就是对准螺栓扳动电源开关,直到把扭剪型高强螺栓的梅花头打断为止。电动定扭矩扳手既可初紧又可终紧,它的使用是先调节扭矩,再紧固螺栓。电动转角扳手主要也属于定扭矩扳手的一种,它的使用是先调节旋转度数,再紧固螺栓。电动角向扳手是一种专门紧固钢架夹角部位螺栓的电动扳手,它的使用和电动扭剪扳手原理一样

  The twist-shear wrench is mainly used to tighten the initial bolt. Its use is very simple, that is, to turn the power switch on the alignment bolt. Electric twist shear wrench is mainly used for the final tightening of high strength twist shear bolts. Its use is to pull the power switch on the alignment bolts until the plum blossom head of the high strength twist shear bolts is interrupted. The electric fixed torque wrench can be tightened both initially and eventually. Its use is to adjust the torque first and then tighten the bolt. Electric angle wrench is also a kind of fixed torque wrench. Its use is to adjust the rotation degree first, and then tighten the bolt. Electric angular wrench is an electric wrench specially designed to fasten the bolts in the angle part of the steel frame. Its use is the same as that of electric torsion shear wrench.
  扭剪扳手主要是终紧扭剪型高强螺栓的,它的目的就是把扭剪型高强螺栓的梅花头打断即可。工作时将扳手头对准螺栓头,扣动开关即可开始工作,几秒后,螺栓梅花头将被扭断,然后抽出扳手扣动扳机将梅花头弹出,即结束工作。
  The twist-shear wrench is mainly used to tighten the twist-shear type high-strength bolt. Its purpose is to break the plum blossom head of the twist-shear type high-strength bolt. When working, the wrench head is aligned with the bolt head, and the switch can start to work. After a few seconds, the bolt plum head will be twisted off, and then pull out the wrench to pull the trigger and pop the plum head out, that is to say, the work will be finished.
  济南万中电动扳手有限公司致力于电动扭矩扳手,扭剪扳手家服务,坚持“以客户为中心”的理念,坚持“领域”,积极为客户创造价值。
  Jinan Wanzhong Electric Spanner Co., Ltd. devotes itself to the service of electric torque wrench and twist-shear wrench maker, adheres to the concept of "customer-centered", adheres to the "professional field" and actively creates value for customers.
  扭剪扳手是一种终紧扭剪型高强度螺栓的工具,一般有电动扭剪扳手和手动扭剪扳手,其中电动扭剪扳手比较常见。
  Twist shear wrench is a tool for ultimate tightening and high strength bolts. There are generally electric and manual twist shear wrenches, among which electric twist shear wrenches are more common.
  电动扭矩扳手的特点:(1)使用寿命长(2)手柄和机壳材料散热性好(3)功率大(4)耐撞击性强(5)手使用性价比比较高
  The characteristics of electric torque wrench are: (1) long service life (2) good heat dissipation of handle and shell materials (3) high power (4) strong impact resistance (5) the highest cost performance of hand use.
  常用扭剪扳手螺栓规格:M16*50、16*55、16*60、16*65、16*70、16*75、16*80、20*50、20*55、20*60、20*65、20*70、20*75、20*80、22*50、22*55、22*60、22*65、22*70、22*75、22*80、24*60、24*65、24*70、24*75、24*80、24*85、24*90
  Specifications of commonly used twist-shear wrench bolts: M16*50, 16*55, 16*60, 16*65, 16*70, 16*75, 16*80, 20*50, 20*60, 20*65, 20*70, 20*75, 20*80, 22*50, 22*55, 22*60, 22*65, 22*65, 22*65, 22*70, 22*70, 22*75, 22*80, 24*60, 24*65, 24*70, 24*75, 24*80, 24*85, 24*90
  扭剪扳手的应用: 扭剪型高强螺栓的初紧可使用冲击电动扳手或定扭矩扳手,而终紧必须使用扭剪扳手,所以扭剪扳手是专门终紧扭剪型高强螺栓的。扭剪扳手的使用: 扭剪扳手主要是终紧扭剪型高强螺栓的,它的目的就是把扭剪型高强螺栓的梅花头打断即可。工作时将扳手头对准螺栓头,扣动开关即可开始工作,几秒后,螺栓梅花头将被扭断,然后抽出扳手扣动扳机将梅花头弹出,即结束工作。

  Application of Torsion-shear wrench: The initial tightening of Torsion-shear high-strength bolt can use impact electric wrench or fixed-torque wrench, and the final tightening must use Torsion-shear wrench, so the Torsion-shear wrench is specially designed for the final tightening of Torsion-shear high-strength bolt. Use of torsion shear wrench: The main purpose of torsion shear wrench is to break the plum blossom head of torsion shear high strength bolt. When working, the wrench head is aligned with the bolt head, and the switch can start to work. After a few seconds, the bolt plum head will be twisted off, and then pull out the wrench to pull the trigger and pop the plum head out, that is to say, the work will be finished.
  扭剪扳手的特点: 操作方便、省时省力、安全方便
  The characteristics of torsion shear wrench: easy to operate, time-saving, labor-saving, safe and convenient
  另外说明扭钜和扭剪电动扳手是不能通用的
  It also shows that the electric wrench with large torsion and shear can not be used.
