扭剪型电动扳手采购要注意哪些事项?

来源:https://www.xjnwz.com 日期:2020-12-18 发布人:admin

1:配套测力计的安装方法:

1: Installation method of supporting dynamometer:
1)传感器内置式:将4-M6螺丝穿入固定块4-中6.2孔中,在螺纹方向各套入1个垫圈,并与侧力计安装板上4-M6螺纹旋紧,测力计安装板上,测力计安装孔分为两组,分别为30x145. 40x90。用户可根据自己的需要确定。
1) Built in sensor: insert 4-m6 screw into 6.2 hole in 4-middle of fixed block, insert a washer in thread direction, and screw it with 4-m6 thread on side force meter mounting plate. On dynamometer mounting plate, dynamometer mounting hole is divided into two groups, 30x145.40x90. Users can determine according to their own needs.
2)传感器外置式:将2-M8螺丝穿入固定块2-中8.5孔中,并与连接杆上2-M8螺丝旋紧。将M12螺母穿入连接杆通孔内并与传感器旋紧即可,操作系统可安装在外置式侧力计安装板上。
2) Sensor external type: insert the 2-m8 screw into the 8.5 hole in the fixed block 2 - and tighten it with the 2-m8 screw on the connecting rod. The operating system can be installed on the mounting plate of external lateral force meter.
扭剪型手动扳手制造厂家|扭剪型手动扳手维修电话,2:操作面板使用方法:
Manual wrench manufacturer | maintenance telephone number of twist shear type hand wrench, 2: operation panel usage:
l)电源开关:当按下按钮时,接通电源,再次按下,电源断开。
l) Power switch: when the button is pressed, turn on the power supply, press it again, and the power supply will be disconnected.
扭剪扳手
2)速度操作:由于被测物体及用户要求的不同,当调整调速器旋钮时,载体的运动速度为60-300m/min.
2) Speed operation: due to the different requirements of the tested objects and users, when the governor knob is adjusted, the motion speed of the carrier is 60-300m / min
3:功能操作:
3: Function operation:
手动/自动,当将旋钮旋至手动时,如使载体运动,则需按住升(up)或降(DOWN)键,断开则运动停止。当旋钮旋至自动时,如使载体运动则直接按升(up)或降(DOWN)键。
Manual / automatic: when the knob is turned to manual, if the carrier moves, press and hold the up or down key, and the movement will stop if it is disconnected. When the knob is turned to automatic, if the carrier moves, press the up or down key directly.
4:测力计高度调整:
4: Height adjustment of dynamometer:
SHAEV双柱立式机台固定块两侧为M8锁紧镖钉,首先将M8锁紧镖钉松开,将固定块向上或向下移动到所需要的高度后,将M8螺钉锁紧。
Both sides of the fixed block of shaev double column vertical machine are M8 locking dart nails. First, loosen the M8 locking dart nail, and then lock the M8 screw after moving the fixed block up or down to the required height.
扭剪型手动扳手制造厂家|扭剪型手动扳手维修电话, 5:行程调整:
Manual wrench manufacturer | maintenance telephone number of twist shear type hand wrench, 5: stroke adjustment:
导柱上十字槽螺钉为大行程的1,限位套为用户测量所需行程调节套。计数器使用方祛:计数器上方为数字显示屏、记录试验次数,下方为预置按钮(左1一4),右1为倍率按钮(ix. 10X, ioox)如:用户对某一产品进行连续测试,侧试次数为5倍率为lox,则测试架往复10次显示屏显示为1,运行50次后自动停止,如需再次测试,按停止按钮即可。
The cross groove screw on the guide post is 1 of the large stroke, and the limit sleeve is the stroke adjusting sleeve required by the user for measurement. How to use the counter: the top of the counter is a digital display screen to record the number of tests, and the bottom is the preset button (1-4 on the left), and 1 on the right is the multiple button (IX. 10x, ioox). For example, if the user continuously tests a certain product and the side test times are 5 and the ratio is LOX, the test rack will repeat 10 times, and the display screen will display 1, and it will stop automatically after running 50 times. If you need to test again, press the stop button.
